Dura-Coat Rubber-Flex 900 S
Technical Data Sheet
DESCRIPTION AND RECOMMENDED USES: 100% solids, Dura-Coat Rubber Flex 900S is a high elongation hybrid-urethane elastomer. It is ideal for repairing rubber surfaces and is fully compatible for coating metals and other substrates. The elastomeric appearance provides high strength and flexibility, while the ceramic reinforcement provides improved abrasion resistance. It is ideal for repairing screens, pulleys, and tanks with rubber coatings. Dura-Coat Rubber Flex 900S is a lightweight paste and can be easily applied up to 500 mils without slipping.
- It can be applied up to 500 mils without slump
- Ideal for rubber protection and repair
- Suited for screens, pulleys and tanks
- Suited for immersion and non-immersion services
Application Areas:
- Rubber in general
- Tanks
- Screens
- Pumps
- Pulleys
- Other
- Rubber in general
Package
- Size 750g | Reorder # 900S-750
Technical Data
Application Sheet
Surface Preparation: Proper surface preparation is crucial for the long-term performance of Dura-Coat Rubber-Flex 900S. The surface must be clean and roughened. Prepare by mechanically cleaning with a rotating wire brush. Clean with solvents (acetone, xylene, alcohol, or MEK) and a cloth. It is not necessary to apply primer; Dura-Coat Rubber-Flex 900S is applied directly to the rubber or metal.
Mixing: Mix the activator thoroughly into the base using the mixing rod, scraping the sides and bottom of the container. Mix by weight, 9 parts base to 1 part activator. Mix thoroughly to produce a uniform and streak-free material. Never add solvents.
Application: Dura-Coat Rubber-Flex 900S can be applied by squeegee, spatula, or caulking gun.
To prevent slipping on vertical surfaces, the maximum thickness per coat should be up to 12.7 mm (500 mils) per coat.
FDA Compliance: This product complies with FDA regulations, for direct food contact specifically FDA 21 CFR 175.300 and FDA 21 CFR 175.105.
| Maximum Temperature (Dependent on service) | Wet Service | Dry Service | -30°C | 93°C | -22°F | 200°F |
|---|---|---|---|
| Chemical Resistance | Water | Alkalis | Inorganic Acids | Organic Acids | Organic Solvents | Excellent | Excellent | Excellent | Fair | Poor | |
| Elongation | 200% | ||
| Specific Gravity | 1.5 | ||
| Viscosity | Light paste | ||
| Hardness | 105 Shore A | ||
| Vertical SAG Resistance at 21ºC (70ºF) and 12.7mm (500mils) | No sag | ||
| Coverage for 750g kit | 7.2sf @40mils | 0.67m2 @1mm | |
| Mix Ratio | 9:1 by weight | Base: Activator | |
| Color | Black | ||
| Shelf Life (unopened containers) | 3 years at 55-95ºF (13-35ºC) | ||
Videos
Cured Time
| 16°C (60°F) | 25°C (77°F) | 32°C (90°F) | |
|---|---|---|---|
| Tack Free | 2 hours | 1.5 hours | 1 hour |
| Light Load | 2 hours | 1.5 hours | 1 hour |
| Overcoat End | 2 hours | 1.5 hours | 1 hour |
| Full Load | 2.5 hours | 2 hours | 1.5 hours |
Clean Up
Tools must be immediately cleaned after usage by using industrial alkaline detergent.
Safety
Before using any products, review the appropriate Safety Data Sheet (SDS) or Safety Sheet for your area. Follow standard confined space entry and work procedures, if appropriate.
Manufacturer, Dura-Coat Industrial Inc., makes no warranty either expressed or implied including warranties of merchantability or fitness for a particular purpose for this product. Under no circumstances will the manufacturer be liable for incidental, consequential, or other damages, breach of warranty, strict liability, or any other theory arising out of use of this product. The information and or recommendations contained herein are based on standard Product and are proprietary and furnished solely for the use of our customers. This information is provided in good faith and believed to be true and accurate as of the date/version of this document. As the manufacturer has no control over the use conditions or application process of the parties using this product, the manufacturer cannot accept responsibility for loss, injury or other damages resulting from the use of the Product or this or any other information provided by the manufacturer. Therefore, no guarantees of any kind, expressed or implied, are made by the manufacturer, Dura-Coat Industrial Inc., regarding this, or any, product manufactured by them or any contracted or licensed manufacturer. DURA-COAT® epoxy products do not provide structural integrity or improvement. They are only used to provide protection from corrosion, wear, abrasion and chemical attack on a given substrate and only to the extent provided for in the Data Sheets, Technical Data Sheets, Safety Data Sheets, and any other information as supplied in writing directly from manufacturers technical support.
Revision: 4/2024
